GEMS Westminster School

Project Overview

The documented scope for GEMS Westminster School included structural design criteria, loading plans, structural modeling, drawings, calculations, and an LOD 300 model for municipality approval.

Scope of Work

Design criteria and loading plans
Markup plans identifying load-bearing and external vertical elements
ETABS model
General arrangement drawings
Typical connection details
Structural drawing and calculation submissions
Municipality approval documentation
LOD 300 model for municipality approval

Structural Drawings

The documented drawing package includes:

General arrangement of each floor
Hollowcore slab layouts
Ground-level dowel bar layout
Sections and elevations
Wall sections
Connection details
Typical reinforcement details
Floor plans showing special reinforcement

GEMS Westminster School Structural Drawings

Engineering Calculations

The specified calculation files and subjects include PROKON, SAFE, Concise, and ETABS, with pier and spandrel calculations, dowel bar calculations, corbels, nibs, and diaphragms.

BIM Deliverables

The project scope specifies a generic LOD 300 model for municipality approval, with structural element sizes matching the AutoCAD drawings.
